Veterinary Automatic POCT Hematology Analyzer PB30V
Monotest cartridge, free of reagents
Impedance method used for CBC measurement
Requires 20 ul of whole blood, specifically fingertip blood
One-step operation with TAT in 4 minutes
1. Real-time testing
It helps to streamline the testing process and provide accurate results quickly, allowing veterinarian to identify and address any issues promptly.
2. Accurate test results
Hematology analyzers with high accuracy can provide precise test results to help doctors make accurate diagnosis and treatment decisions.
3. Small size and portable
Small and portable hematology analyzers usually have a compact design for easy portability and operation.
4. Easy to use
Clear user interface and simple and intuitive operation process can reduce misuse.
Test Principle | Impedance method、Coulter principle、Colorimetry、Immunonephelomety |
Parameters | 21 blood routine parameters+ 3 specificprotein measurement+ 3 histograms |
Sample type | Capillary whole blood, venous whole blood |
Sample volume | 20μL |
Throughput | ≥18 samples per hour |
Display | 10.1 inch touch screen |
Data capacity | UP to 200,000 results including numeric and graphical information |
Interface | 4 USB ports, Wifi，WLAN, HDMI; Support bi-directional LIS |
Printout | External laser/inkjet printer |
Power voltage | AC100V-240V; 50-60HZ |
Operating environment | Temperature: 10℃~32℃; Humidity: 20%~85%; Air pressure: 70kPa~106kPa |
Dimension & weight | 259mm×288mm×313mm; 9.8kg |
Parameter | Linearity Range | Precision |
WBC(10/L) | 0.00~300.00 | ≤2.5% |
RBC(101²/L) | 0.00～8.50 | ≤1.5% |
HGB(g/L) | 0~250 | ≤1.5% |
HCT（%） | 0.0~75.0 | ≤1.5% |
PLT (10°/L) | 100~500 | ≤4.0% |
