Auto Hematology Analyzer MX5200
2. One-touch operation
It ensures efficient operating, enhancing productivity and efficiency.
3. Accurate and excellent
Its high level of accuracy ensures that users can rely on the data and make informed decisions based on the system’s outputs.
Test Principle | Impedance method、Coulter principle、Colorimetry、 Flow cytometry technology+laser light scattering、5-part differential analysis |
Parameters | 25 parameters: WBC、Lym#、Lym%、Mon#、Mon%、Eos#、Eos%、Neu#、 Neu%、Bas#、Bas%、RBC、RDW-CV、RDW-SD、HGB、MCV、MCH、MCHC、 HCT、PLT、MPV、PDW、P-LCR、P-LCC、PCT 6 research parameters: ALY#、ALY%、LIC#、LIC%、NRBC#、NRBC% 3 Histograms：WBC、RBC、PLT 3 WBC Abn Scattergrams、3D Scatter Plot |
Reagents | DIL diluent、MX-H1 lyse、MX-H2 lyse、MX-H3 lyse、CLE-P cleanser |
Sample volume | Prediluent mode: 20μL; Whole blood mode: 15μL |
Throughput | 60 samples per hour |
Display | 13.3 inch touch screen |
Data capacity | UP to 100,000 results including numeric and graphical information |
Interface | USB, LAN, HDMI; Support bi-directional LIS |
Printout | External laser/inkjet printer |
Power voltage | AC100V-240V; 50-60HZ |
Operating environment | Temperature: 10℃~30℃; Humidity: 20%~85%; Air pressure: 70kPa~106kPa |
Dimension & weight | 380mm×460mm×530mm; 42kg |
Parameter | Measuring Range | Range of relative deviation allowed (%) |
WBC | (3.5～9.5)×109/L | Not more than±15% |
RBC | (3.8～5.8)×1012/L | Not more than±6% |
HGB | (115～175) g/L | Not more than±6% |
MCV | (82～100) fL | Not more than±7% |
PLT | (125～350)×109/L | Not more than±20% |
