Veterinary Hematology Analyzer MX60V
· Up to 60 samples per hour
· 29 parameters + 4 scattergrams + 2 histograms
· 10.4 inch large TFT touch screen
· 12 user-defined animals species
Easy to Use
· One button analysis
· Smart maintenance system
· Independent operating system
· Multi-language supported
· External barcode scanner
Throughput | 60 samples / hour |
Sampling modes | Whole blood, Capillary whole blood, Pre-diluted sample |
Sample volume | Whole blood: 20μL, Capillary whole blood:20μL, Pre-diluted mode: 20μL |
Test modes | CBC+DIFF |
QC Mode | L-J, X-B |
Storage Capacity | 50,000 results memory with scattergrams and histograms |
Species of animals | Cat, dog, mouse, rabbit, horse, pig, cattle, deer, monkey, sheep, bird, chicken |
Physical Characteristics | |
Display | 10.4 inch colour touch screen |
Machine Dimension&Weight | Width x Height x Depth: 325mm*465mm*470mm, Weight: 30Kg |
Package Dimension&Weight | Length x Width x Height: 630mm*490mm*630mm, Weight: 35Kg |
Working temperature | 10-30℃ |
Relative Humidity | 70% max |
Reagents | |
Diluent | 20L×1 |
Lyse | 60DIFF(500mL×1), 60LH(100mL×1) |
Probe cleanser | 100mL×2 |
Precision | ||
Measurement | Measuring Range | Repeatability Limits Whole Blood(CV) |
WBC | 3.5-15.0x109/L | ≤ 2.0% |
RBC | 3.5-6.0x1012/L | ≤ 1.5% |
HGB | 110.0-180.0 g/L | ≤ 1.5% |
MCV | 70.0-120.0 fL | ≤ 1.0% |
PLT | 150.0-500.0x109/L | ≤ 4.0% |
Linearity | ||
Measurement | Measuring Range | Limit |
WBC | 0-100x109/L | ± 0,3 or ± 5% |
RBC | 0-8x1012/L | ± 0,05 or ± 5% |
HGB | 0-250 g/L | ± 2 or ± 2% |
PLT | 0-1000x109/L | ± 10 or ± 8% |
