Immunofluorescence Analyzer MF100V
Portable and compact design, catering to diverse healthcare settings and patient populations.
2. Results in as fast as 3 minutes
Reduce waiting time and improve detection efficiency.
3. Store reagents at room temperature
Many reagents retain their stability and performance at room temperature for extended periods of time, ensuring longer shelf life and reducing the risk of expiration or waste.
Methodology | Time-resolved fluorescence immunochromatography |
Excitation spectra | 365nm |
Emission spectra | 610nm |
Sample type | Whole blood/plasma/serum；Nasopharyngeal and eye discharges；Rectal swab |
Sample volume | 100 μl |
Test throughput | 200T/H |
Test time | 3-15min |
Reagent storage condition | Room temperature |
Reagent shelf life | 24 months |
Calibration reading | Code card |
Applicable card | Single card, triple100*16*4.8 mm |
Barcode of card | QR code |
Accuracy | CV ≤3% |
Data storage | 50,000 pieces |
Printer | Built-in thermal printer |
Operating system | Android 4.4 (7.0 inch), support LIS system |
Supply voltage | AC100V-240V，50-60HZ |
Size | 24*21.4*12cm |
Weight | <3kg |
Category | No. | Test items | Sample type | TAT |
Inflammation | 1 | CRP | Whole blood/plasma/serum | 3 min |
2 | fSAA | Whole blood/plasma/serum | 5 min | |
3 | cPL | Plasma/serum | 15 min | |
4 | fPL | Plasma/serum | 15 min | |
Antigen | 5 | CDV-Ag | Nasopharyngeal and eye discharges | 10 min |
6 | CPV-Ag | Rectal swab | 10 min | |
7 | CCV-Ag | Rectal swab | 10 min | |
8 | FPV-Ag | Rectal swab | 10 min | |
9 | FHV-Ag | Nasopharyngeal and eye discharges | 10 min | |
10 | FCV-Ag | Nasopharyngeal and eye discharges | 10 min | |
11 | FHV-FCV Ag | Nasopharyngeal and eye discharges | 10 min | |
12 | FCoV-Ag | Rectal swab | 10 min | |
13 | HP-Ag | Rectal swab | 10 min | |
14 | Giardia‐Ag | Rectal swab | 10 min | |
15 | CPV/ CCV-Ag | Rectal swab | 10 min | |
16 | FPV/ FCoV-Ag | Rectal swab | 10 min | |
17 | FeLV-Ag | Plasma/serum | 10 min | |
Antibody | 18 | CPV-Ab | Plasma/serum | 10 min |
19 | CDV-Ab | Plasma/serum | 10 min | |
20 | CAV-Ab | Plasma/serum | 10 min | |
21 | cLSH-Ab | Plasma/serum | 10 min | |
22 | cTOXO-Ab | Plasma/serum | 10 min | |
23 | FPV-Ab | Plasma/serum | 10 min | |
24 | FHV-Ab | Plasma/serum | 10 min | |
25 | FCV-Ab | Plasma/serum | 10 min | |
26 | FIV-Ab | Plasma/serum | 10 min | |
27 | CPV/CDV/CAV Ab | Plasma/serum | 10 min | |
28 | FPV/FHV/FCV Ab | Plasma/serum | 10 min | |
29 | cEHR-Ab | Plasma/serum | 10 min | |
Heart failure | 30 | cNT-proBNP | Plasma/serum | 15 min |
31 | fNT-proBNP | Plasma/serum | 15 min | |
32 | ccTnI | Plasma/serum | 15 min | |
33 | fcTnI | Plasma/serum | 15 min | |
Renal failure | 34 | cCys C | Plasma/serum | 10 min |
35 | fCys C | Plasma/serum | 10 min | |
36 | SDMA | Plasma/serum | 10 min | |
Reproduction | 37 | cProgesterone | Plasma/serum | 10 min |
38 | cRelaxin | Plasma/serum | 10 min | |
Others | 39 | cTT4 | Plasma/serum | 2 min+10 min |
40 | fTT4 | Plasma/serum | 2 min+10 min | |
41 | cTSH | Plasma/serum | 10 min | |
42 | cCortisol | Plasma/serum | 10 min |
Parameter | Measuring Range | Range of relative deviation allowed (%) |
WBC | (3.5～9.5)×109/L | Not more than±15% |
RBC | (3.8～5.8)×1012/L | Not more than±6% |
HGB | (115～175) g/L | Not more than±6% |
MCV | (82～100) fL | Not more than±7% |
PLT | (125～350)×109/L | Not more than±20% |
