Klinogicare VET
Real-time PCR Analyzer
Pointcare® PCR V1
Real-time PCR Analyzer
Pointcare® PCR V1
To satisfy the increasing demands of molecular detection, PCR instruments need to deliver fast-cycling protocols and accurate, sensitive results. MNCHIP Pointcare® PCR V1 Real-Time PCR System is designed for users who need an affordable, easy-to-use real-time PCR system that doesn’t compromise performance and quality. The simplified design and analysis software is ideal for both first-time and experienced users. For quick and accurate test results delivered where needed, when needed, improving the efficiency of operations and providing a flexible, long-term solution.
Features & Benefits
Express detection
Comprehensive results in about
60 minutes.
60 minutes.
Easier to use
Built-in ultrasonic mixing device to
replace manual mixing, reducing
the need for manual manipulation.
replace manual mixing, reducing
the need for manual manipulation.
Cost-effective
Comparatively affordable analyzer and test kits.
Lower shipping cost with 2-30℃ shipping environment.
Lower shipping cost with 2-30℃ shipping environment.
Technology
MNCHIP fluorescence-based Real-time PCR utilizes a bottom-illumination optical detection system and repeated thermal cycling for DNA detection. Each cycle involves three steps: denaturation, annealing, and extension. By continuously collecting fluorescence data using TaqMan detection principle, the system automatically draws real-time amplification curves.
Operation
Obtain sample
Transfer sample to tube
Insert tube and start test
Read results
Dimensions: 260mm(L)×230mm(W)×320mm(H)
Weight: 5.5kg
Sample Type: Anticoagulant additives whole blood, serum or plasma.
Sample Size: 100µL
Test Time: 8-10 minutes
Quality Control Features: Built-in real-time Quality Control (rQC®) system
Communication: Bi-directional input/output
Interfaces: WIFI, USB, Bluetooth.
Memory Capacity: Up to 50,000 patient and quality control results.
Consumables: 7.8cm in diameter and 0.68cm thick, single-use, self-contained plastic chemistry reagent discs. Each disc contains all reagents needed to perform a panel of tests on a single sample.
Data Input Display: 8.0 inch capacitive touchscreen
Print Report: Built in thermal printer, External Printer via MNCHIP Medical Data Management Platform.
Mode of Opertion: Continuous
Ambient Temperature: 10~30℃(50–86 ºF), indoor use.
Power Requirements: 120 VA
Main Supply Voltage: 100-240 volts AC, 50-60 Hz.
Humidity: 40%~85%
Reaction Temperature: 37℃±0.2℃
Power Bank: Capable
Weight: 5.5kg
Sample Type: Anticoagulant additives whole blood, serum or plasma.
Sample Size: 100µL
Test Time: 8-10 minutes
Quality Control Features: Built-in real-time Quality Control (rQC®) system
Communication: Bi-directional input/output
Interfaces: WIFI, USB, Bluetooth.
Memory Capacity: Up to 50,000 patient and quality control results.
Consumables: 7.8cm in diameter and 0.68cm thick, single-use, self-contained plastic chemistry reagent discs. Each disc contains all reagents needed to perform a panel of tests on a single sample.
Data Input Display: 8.0 inch capacitive touchscreen
Print Report: Built in thermal printer, External Printer via MNCHIP Medical Data Management Platform.
Mode of Opertion: Continuous
Ambient Temperature: 10~30℃(50–86 ºF), indoor use.
Power Requirements: 120 VA
Main Supply Voltage: 100-240 volts AC, 50-60 Hz.
Humidity: 40%~85%
Reaction Temperature: 37℃±0.2℃
Power Bank: Capable
