Methodology | Time-resolved fluorescence immunochromatography |
Excitation spectra | 365nm |
Emission spectra | 610nm |
Sample type | Whole blood/plasma/serum;Nasopharyngeal and eye discharges;Rectal swab |
Sample volume | 100 μl |
Channel | 6 |
Test time | 3-15min |
Reagent storage condition | Room temperature |
Reagent shelf life | 24 months |
Calibration reading | Code card |
Applicable card | Single card, triple100*16*4.8 mm |
Barcode of card | QR code |
Accuracy | CV ≤10% |
Data storage | 50,000 pieces |
Interface | Built-in thermal printer, WIFI, USB or RS232 |
Operating system | Android 5.1 (8.0 inch), support LIS system |
Supply voltage | AC100V-240V,50-60HZ |
Size | 280×275×165mm |
Weight | 3.8kg |
